Powerwall battery pack buitl-in 10KW inverter 3-phase 48V ALL in One ESS 20KWh 15KWH 51V 400Ah 300Ah LiFePO4 WiFi Monitor

All-in-one home battery system with LiFePO4 pack, built-in 10kW inverter, 48V 3-phase, 15kWh/20kWh storage options, 300Ah–400Ah capacity, and smart WiFi monitoring. Reliable, safe, and perfect for solar energy storage.

SKU: ESS2509282050 Category: Tag:

3-phase 48V Powerwall AC380V 20KWh 15KWH ALL in One ESS 51V 400Ah 300Ah LiFePO4 Battery Pack Buitl-in 10KW Inverter WiFi Monitor

3-phase 48V Powerwall AC380V 20KWh 15KWH ALL in One ESS 51V 400Ah 300Ah LiFePO4 Battery Pack Buitl-in 10KW Inverter WiFi Monitor 4

3-phase 48V Powerwall AC380V 20KWh 15KWH ALL in One ESS 51V 400Ah 300Ah LiFePO4 Battery Pack Buitl-in 10KW Inverter WiFi Monitor 5

3-phase 48V Powerwall AC380V 20KWh 15KWH ALL in One ESS 51V 400Ah 300Ah LiFePO4 Battery Pack Buitl-in 10KW Inverter WiFi Monitor 2

Efficient Energy Management for Homes and Businesses

Explore the ultimate solution to your energy storage needs with our Powerwall Battery Pack. Designed with cutting-edge technology, this all-in-one energy storage system combines reliability and versatility to deliver seamless power management for residential and commercial applications. With its built-in 10KW inverter, 3-phase compatibility, and WiFi monitor, this system ensures that you stay connected and maintain control of your energy usage efficiently.

Robust Features That Deliver Maximum Performance

Crafted to meet the highest standards, this Powerwall is equipped with a 48V LiFePO4 battery offering 20KWh and 15KWh storage capacity options. With an impressive 51V 400Ah or 300Ah configuration, it caters to different power requirements seamlessly. By harnessing LiFePO4 technology, this system guarantees higher energy density, lower environmental impact, and improved safety compared to traditional batteries. The unit’s built-in 10KW inverter ensures robust power delivery and flexibility for 3-phase setups, ideal for demanding energy systems.

Smart and Convenient Power Monitoring

Take the guesswork out of energy storage with the integrated WiFi monitor. This innovative feature allows you to track performance in real-time, optimize energy usage, and identify patterns in your electricity consumption. Whether you want to make smarter decisions for your home or optimize operations for your business, the convenience of remote monitoring puts control at your fingertips. Compact in design but powerful in function, this all-in-one energy storage system creates opportunities for more efficient power use.

Why Choose Our Powerwall Battery Pack?

Our Powerwall Battery Pack stands out in the market due to its advanced design and dependable performance. The combination of a built-in 10KW inverter, scalable energy storage with a 48V LiFePO4 battery, and intuitive WiFi monitoring makes it an excellent choice for anyone needing long-term energy storage solutions. Whether you are preparing for peak energy demand, planning for off-grid living, or simply trying to reduce energy bills, this system has you covered.

Product Specification

Type

TW-AO-MB51300-AC380V-10KW-EU

TW-AO-MB51400-AC380V-10KW-EU

TW-AO-MB51400-AC380V-12KW-EU

SKU

15KWH-10KW-AC380V

20KWH-10KW-AC380V

20KWH-12KW-AC380V

BATTERY TECHNICAL SPECIFICATION

Battery model

TW-MB51300-200A-HWB

TW-MB51400-200A-HWB

Number of batteries 1Battery Pack (32pcs cells)
Battery Energy

15360Wh

20480wh

Battery Capacity

300Ah

400Ah

Battery Type

LiFePO4

Battery Rated Voltage 51.2V
Battery Working Voltage Range 44.8~57.6V
Maximum Charging Current 200A
Maximum Discharging Current 200A
DOD Designed Life-span >6000 Cycles @ 0.2c/25’℃ charging/Discharging at 80%DoD,Until 80%

INVERTER TECHNICAL SPECIFICATION

INVERTER TECHNICAL
PV CHARGE

ASF48100SH3

ASP48120SH3

Solar Charge Type MPPT
Maximum Output Power

7500W

9000W

Maximum PV Charging Current 22/22A
Maximum PV Operating

Voltage

800Vdc/800Vdc
MPPT Voltage Range 200-650Vdc/200-650Vdc

AC CHARGE

Input Voltage Range

Phase voltage 170~280v, line voltage 305~485V

Input frequency range 50/60H
Bypass Overload phase Current

29A

35A

ACOUTPUT

Rated Output Power 10000W 12000W
Frequency 50Hz+0.3Hz/60Hz+0.3Hz
switching time 10ms(Typical value)

EFFICIENCY

MPPT tracking efficiency 99%
Maximum efficiency of battery inverter ≥92%
European efficiency 97.50%

GENERAL DATA

Communication RS485/CAN/WIFI
Storage time/temperature 6 months @25℃;3 months @35℃;1 months @45℃;
Charging temperature range 0〜45℃
Discharging temperature range -10〜45℃
Operation Humidity 5% 〜 85%
Nominal Operation Altitude <2000m
Cooling Mode Force-Air Cooling
Ingress Protection Rating IP20
Recommended Operation

Environment

Indoor
Weight 300 lbs
Cells

Brand-new lithium iron phosphate LiFePO4 batteries

Cell Brands

EVE, WELION, CATL, Hithium, REPT, GOTION

Place of Origin

China

Certification

TUV, CB, UN38.3, MSDS, IEC62619, IEC62040, IEC61000, CEC, TISI

BMS Brand

PACE
